OMR8
by OKUR
OKUR (OMR8) 8″ PRO AUDIO MID-RANGE HIGH OUTPUT
FEATURES:
- CCAW Voice Coil Wire
- KSV Coil
- Ferrite Magnet
- Stamped Steel Basket
- Paper Cone
- Cloth Cone Edge
T/S PARAMETERS:
- Resonant Frequency (fs) : 96.2Hz
- D.C. Voice Coil Resistance (Re) : 5.8
- Mechanical Quality Factor (Qms) : 6.74
- Electrical Quality Factor (Qes) : 1.84
- Total Quality Factor (Qts) : 1.45
- Compliance Equivalent Volume (Vas) : 13.9L
- BL Product (BL) : 5.1
- Diaphragm Mass inc. Airload (Mms) : 13.6 gr
ADDITIONAL SPECS:
- Basket Diameter : 8″ (203.2mm)
- Max Power : 350 Watts
- Nominal Power : 75 Watts
- Impedance : 8 Ω
- Resonance : 96.2Hz
- Sensitivity : 96.5
MOUNTING INFORMATION:
- Overall Diameter : 8.22″ (209mm)
- Cutout Diameter : 7.14″ (181.50mm)
- Mounting Depth : 2.68″ (68.30mm)
