COM94QVPRO
by AIS
AIS (COM94QVPRO) PRO SERIES COMMERCIAL 4 CHANNEL QUAD VIEW CAMERA INPUT
The COMPRO-Series monitors was designed to give a high-end quality solution, while maintaining the ruggedness for commercial use.
REQUIREMENT:
- For use with cameras that have the RCA video connector on them, the COMRCAADPF is required for each camera you intend to use with this monitor.
FEATURES:
- 9" 16:9 wide screen.
- Video input: 4
- Multi-Camera Quad View
- Stainless Steel Aviation connectors.
- Monitor provides POWER/GROUND for the each camera.
- Resolution:800*RGB*480
- Separate trigger control wire for each camera.
- System:PAL & NTSC optional
- Power:12~32VDC
- Automatic switch-over to the image to the corresponding triggered camera and back to the original mode when the trigger stops.
- Multiple menu languages: English, Dutch, French, Portuguese, Spanish, Russian, German, Italian
- Normal, Flip, Mirrored, Mirrored Flip picture can be switched separately on each camera.
- Customizable guide lines.
- Adjustable trigger time delay (1-5 seconds) on each camera.
- Vehicle Fitment : Commercial Vehicles
